Wants more? Check out the impressive gameplay in ATI Eyefinity 6060 x 1200 resolution
HIS 5970 Key Advantage
- The fastest graphics card on the planet
- Offer the power of Dual 5800 GPUs and 3200 stream processors
- More than 4 teraFLOPS of processing power
- Increase the gaming performance up to 180% with ATI CrossFireXTM Technology in dual-mode with quad GPU support
- DirectX® 11 and DirectCompute 11 functionality complete support
- ATI Eyefinity - Run up to 3 displays from a single graphics board and expand your gaming field of view across all displays*
- ATI Stream - Tap into the massiveparallel processing power of your GPU and tackle demanding tasks like video transcoding with incredible speed
- Max Resolution: 3 x 2560x1600!!!
- Bundle with the World's First DirectX® 11 Game DiRT® 2TM & HIS Gamer's Tool Kit
The World's Most Powerful and Advanced GPU
With more than 4 teraFLOPS powering dual 2nd generation TeraScale engines, the ATI RadeonTM HD 5970 delivers unprecedented graphics performance with latest and most demanding games. Gamers can even increase the gaming performance up to 180% with ATI CrossFireXTM Technology in dual-mode with quad GPU support!!!
The new king is here, all hail the Radeon HD 5970 ~ Guru3D Top Pick
" And in the comparative chart we can start to evaluate again. This card is really really fast. Check for example a Radeon HD 4870 which is a brilliant performing card. It's pushing 26 FPS here at 1920x1200. A GeForce GTX 285 poops out 35 FPS, the GTX 295 really is going strong. But it'll have to forfeit to the Radeon HD 5970 which is pushing out a very respectable 61 FPS on average" - Stunning benchmark by Guru3D
" Check that out, scaling from one towards 2 GPU is already decent enough. But popping in another 2 GPU (one 5970) definitely shows massive rendering muscle (!) " Stunning benchmark by Guru3D
Best Performance graphics and even better in Crossfire Setup - TechPowerUp Editor's Choice
" If you want to build the fastest rig money can buy then a HD 5970 CrossFire setup is what you need. " - Benchmark From TechPowerUp
It easily overpowered the NVIDIA GeForce GTX 295 and was on average about 20% faster - Hardwarezone's 4-stars Award
" Overall, there can be no doubting the power and speed of the new Radeon HD 5970. It is simply blazing fast, and as far as single graphics cards go, nothing in the market comes close. The previous speed king, the GeForce GTX 295, has been utterly outclassed by ATI's newest dual-GPU offering. "
" What's more, it does so by offering very impressive levels of power efficiency. In our tests, it easily overpowered the NVIDIA GeForce GTX 295 and was on average about 20% faster. Despite that, it also managed to achieve markedly lower power consumption figures. This is testament to the new Evergreen chips' efficiency and is certainly amazing, to say the least. " - Benchmark from Hardwarezone Singapore
" I personally think that HAWX was created specifically to be played on three screens of 30 "in 2560 × 1600, the Hemlock. Because I do not how to interpret that term, there is no comparison between the HD5970 and GTX 295 in this benchmark " - Benchmark from Lab501
The Power of HIS
The Excalibur, once owned by the invincible King Arthur, denotes the leader's mighty kingship with its mystical power and fascinating beauty and brings him triumph battle after battle.
Now HIS raises this sword again for gamers.
The Legend reborn... Prepare to conquer the gaming world!
The World's 1st DirectX® 11 Game Inside: DiRT® 2TM - Experience the Power of DirectX 11 technology
Behold, our most technologically advanced, feature-rich, graphics processors ever. Plug in for a ridiculously immersive HD gaming experience unlike anything you've ever seen. Or heard. Or felt in the pit of your stomach. Suddenly, you're not just playing Colin McRaeTM : DiRT® 2TM. You're getting dragged through the gravel by it.
Microsoft DirectX® 11 Support
ATI RadeonTM HD 5900 Series GPUs fully support Microsoft DirectX® 11, enabling the following:
- Tessellation is now available to PC developers for real-time rendering with ultra-realistic characters and an incredible level of detail with 3D images
- HDR Texture compression delivers an intense level visual detail without increasing graphics memory footprint with efficiency and incredible image quality
- Multi-threading support for DirectX® 11 accelerates rendering by leveraging all the CPU cores for overall faster gaming performance
- DirectCompute improves PC performance by taking on some or all of a DirectX 11-enabled application's processing load, freeing up the computer's
ATI Eyefinity Technology
Run up to 3 displays from a single graphics board and expand your gaming field of view across all displays. Enjoy the ultimate immersive gaming experience with innovative "wrap around" multi-display capabilities. *
· ATI Eyefinity technology requires one panel with a DisplayPort connector to enable the third display. DisplayPort to DVI dongle is required for panel with DVI connector
Microsoft® Windows 7®
Enjoy all the benefits of Microsoft Windows 7® with ATI RadeonTM HD 5900 Series GPUs which are designed to provide an exceptional experience for the upcoming operating system.
ATI RadeonTM HD 5900 Series Key Features
- Compliant with DirectX® 11 and earlier revisions
- ATI Eyefinity technology with support for up to three displays
- ATI Stream technology
- 3200 Stream Processor
- Designed for DirectCompute 11 and OpenCL
- Accelerated Video Transcoding (AVT)
- GDDR5 memory
- More than 4 teraFLOPS of processing power
- ATI CrossFireXTM multi-GPU support for highly scalable performance
- Supports OpenGL 3.2
- DL-DVI, DL-DVI, Mini DisplayPort
- PCI Express® 2.1 support
- ATI AvivoTM HD video and display technology
- Advanced dynamic power management with ATI PowerPlayTM technology
HIS PRODUCTS ADVANTAGE
- HIS delivers Faster, Cooler, Quieter plus the best quality product!
- Professional customer service and technical support
What's in the box
- HIS Graphics Card
- Power Cable 2x 4pin in, 6pin out
- Power Cable 2x 4pin in, 8pin out
- DVI-I to VGA Adapter
- DVI-I to HDMI Adapter
- Mini-Display Port to Display Port Adapter
- CrossFire Bridge
- Install CD with Multilingual User Guide
- Quick Installation Guide
- HIS Power Up Label
- DiRT2 Game Coupon
- HIS Gamer's Tool Kit
| Model Name | HIS HD 5970 (DirectX 11/ Eyefinity/ Full HD 1080p) HDMI 2GB (2x256bit) GDDR5 Dual DL-DVI / Mini Display Port (HDCP) PCIe (RoHS) (DiRT-2) |
 Chipset |
Radeon HD 5970 PCIe Series |
| ASIC |
RadeonTM HD 5970 GPU |
| Pixel Pipelines |
3200 stream processing units* (Unified) |
| Vertex Engines |
3200 stream processing units* (Unified) |
| Manu. Process (Micron) |
40nm |
| Memory Size (MB) |
2048 |
| Memory Type |
GDDR5 |
| RAMDAC (MHz) |
400 |
| Engine CLK (MHz) |
725 |
| Memory CLK (Gbps) |
4Gbps |
| Memory Interface (bit) |
512 (2x256) |
| Power Supply Requirement |
650 Watt or greater power supply one 75W 6-pin and one 150W 8-pin PCI Express® power connectors recommended (850 Watt with two 75W 6-pin and two 150W 8-pin connectors for ATI CrossFireXTM technology in dual mode) |
| Max. Resolution |
3x 2560*1600 (Dual dual-link) |
| Bus Interface |
PCI Express x16 |
| Display Port (Mini DP) |
Yes |
| HDMI |
No |
| DVI |
Yes |
| 2nd DVI |
Yes |
- ATI Radeon™ HD 5970 System Requirements
- PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard
- 650 Watt or greater power supply one 75W 6-pin and one 150W 8-pin PCI Express® power connectors recommended (850 Watt with two 75W 6-pin and two 150W 8-pin connectors for ATI CrossFireXTM technology in dual mode)
- Certified power supplies are recommended. Refer to http://ati.amd.com/certifiedPSU for a list of Certified products
- Minimum 1GB of system memory
- Installation software requires CD-ROM drive
- DVD playback requires DVD drive
- Blu-rayTM playback requires Blu-ray drive
- For an ATI CrossFireXTM system, a second ATI RadeonTM HD 5970 graphics card, an ATI CrossFireX Ready motherboard and one ATI CrossFireX Bridge Interconnect cable per graphics card are required
Expand, Accelerate, Dominate
The fastest graphics card on the planet, the HIS RadeonTM HD 5970 delivers an unrivaled HD gaming experience so you can play the latest, most demanding HD titles like never before. Engineered for speed, this next-generation powerhouse delivers unprecedented performance straight out of the box. Unlocked, this graphics card has massive headroom so you can take control and push your hardware to its full potential! Expand your visual real estate across up to three displays and get lost in the action with ATI Eyefinity Technology. Using ATI Stream technology, accelerate even the most demanding applications and do more than ever with your PC.5 Among the first to deliver full support for Microsoft DirectX® 11, these GPUs enable rich, realistic visuals with explosive performance so you can dominate your gaming competition.
ATI Eyefinity Technology
Run up to 3 displays from a single graphics board and expand your gaming field of view across all displays. Enjoy the ultimate immersive gaming experience with innovative "wrap around" multi-display capabilities. *
- ATI Eyefinity technology requires one panel with a DisplayPort connector to enable the third display. DisplayPort to DVI dongle is required for panel with DVI connector
- Driver version 8.66 (Catalyst 9.10) or above is required to support ATI Eyefinity technology.
- ATI Eyefinity technology works with games that support non-standard aspect ratios, which is required for panning across three displays.
Microsoft DirectX® 11 Support
ATI RadeonTM HD 5900 Series GPUs fully support Microsoft DirectX® 11, enabling the following:
- Tessellation is now available to PC developers for real-time rendering with ultra-realistic characters and an incredible level of detail with 3D images
- HDR Texture compression delivers an intense level visual detail without increasing graphics memory footprint with efficiency and incredible image quality
- Multi-threading support for DirectX® 11 accelerates rendering by leveraging all the CPU cores for overall faster gaming performance
- DirectCompute improves PC performance by taking on some or all of a DirectX 11-enabled application's processing load, freeing up the computer's
ATI Stream Technology
Thanks to the ATI Stream Technology, developers can now leverage AMD GPUs and CPUs for enhanced application performance and user experience. The massively parallel, programmable GPU architecture delivers dramatic performance and power efficiency
ATI Stream technology is a set of advanced hardware and software technologies that enable AMD graphics processors (GPU), working in concert with the system's central processor (CPU), to accelerate many applications beyond just graphics. This enables better-balanced platforms capable of running demanding computing tasks faster than ever.
Along with leading third party industry partners and academic institutions worldwide, AMD is building a complete ATI Stream computing ecosystem, one that delivers the performance, applications, software and tools necessary to turn AMD's low-cost application acceleration vision into reality.
ATI AvivoTM Technology Enhanced Unified Video Decoder 2 (UVD 2)
Watch the hottest Blu-ray movies or other HD content at full 1080p display resolution and beyond and enjoy a more feature rich experience with enhanced Unified Video
Decoder 2 (UVD 2):
- Enhanced UVD 2 now support hardware acceleration decode of dual 1080p HD video streams
- Brighter Whites processing increases the blue value of white colors for brighter and more vivid video playback
- Independent Video Gamma Control allows you to set video gamma independently from Windows desktop for a better viewing experience
- Dynamic Video Range Control enables user to control levels of black and white during playback
Microsoft® Windows 7®
Enjoy all the benefits of Microsoft Windows 7® with ATI RadeonTM HD 5900 Series GPUs which are designed to provide an exceptional experience for the upcoming operating system.
HIS Radeon graphics chips and Windows 7 graphics driver draws Windows incredibly efficiently - helping to save system memory and enable a superior Windows experience. The Windows 7 Aero desktop was designed using the DirectX 11 API, for which ATI 5900 Series of products provide full support. Besides, they fully supports the new Direct2D API - enabling enhanced 2D graphics features, and anti-aliased text to make applications running under the Windows 7 desktop look amazingly smooth and readable.
ATI CrossFireXTM Technology
- "Take gaming to a new level with plug-n-play ease"
ATI CrossFireXTM multi-GPU technology takes your gaming experience to the next level with superb scalability, performance and compatibility. The technology combines the awe-inspiring capabilities of multiple ATI RadeonTM graphics cards and an ATI CrossFireX ready motherboard to meet the hard-core demands of your alternate reality. New ATI RadeonTM HD graphics cards are designed with an internal ATI CrossFireTM Bridge Interconnect system to simplify installation.
Experience stunning visual realism in today's demanding games with uncompromising image quality, especially on HD displays. ATI CrossFireX: Multiply and Conquer!5
