HIS Multi-View USB 3.0 4K Docking Station ports

Application



1 USB plug in, all connect

Organize all your device and peripherals at once by simply plug in the USB 3.0 cable to your device. Now you can brings your all USB device, monitors, routers, mice, keybroad, speakers monitor, printer together with one USB cable! Turn your Window Tablet and laptop into a control center with 3 monitors with only 1 plug and play action.

1 Docking, support Window 8.1 Tablet & Window 7/8!

Support Tablet with Windows 8.1 and Windows 7/8 base notebook device.

View More, Work Better



Enjoy 3 montiors Multi-tasking by adding up to 2 Monitors on your laptop!  Just connect to the HDMI and DVI port on the docking. Having one dedicated screen just for facebook, 2nd one for email and 4 screens for monitoring is not a dream anymore. Great device for trader, designer, business professional!



Fast charing USB port charge FASTER, save more time!

With access to Fast Charging USB port on the front can charge at 5V/1.5A, enjoy even faster charing time up to 60% than normal USB3.0 and 3 times faster than USB2.0 on phone & tablet.

USB 3.0, Synchronising faster!

Being 10 times faster than USB 2.0, USB 3.0 has transmission speed up to 5 Gbit/s.  A lot of time will be saved on synchronizing and can be spent on more important things. USB 3.0 is backward compatible with USB 2.0 so your old device will be able to communicate with the device without worries.

User Friendly, you get what you plug!

You can see what is running with full control. USB 3.0 is backward compatible with USB 2.0.  So you have no need to worry whether your old devices can be used with the docking.

View More, Enjoy More

It is not a dream anymore by using a HIS Multi-View USB 3.0 4K Docking Station to enjoy 3 monitors for multi-tasking.

Enjoy new 4K Large Screen TV!



The Docking station is equipped with video output supporting the new 4K (3840 x2160 30Hz resolution) standard on the included HDMI and DP ports*. On the retail version of this product rhere is a slider to select either the HDMI or DP port. Note that using the HDMI port and DP port simultaneously is not possible. When connecting a 4K monitor, the dual monitor functionality is disabled.

*Please note that 4K can be supported one port at a time, not both DP and HDMI simultaneously







Features

• USB 3.0 downstream port x3
• Downward compatible with USB 2.0/1.1
• One USB port supports BC 1.2 charging
• Display Port
• DP/HDMI: resolution up to 3840x2160 pixels
• DVI: resolution up to 2048x1152 pixels
• Support sudio 2.1 channel
• Support Gigabit Ethnet

NOTE: Please note that when using the DP (or HDMI) and the DVI connector simultaneously, the DP (or HDMI) connector will not be able to reach 4K resolutions.

Package Contents

• USB 3.0 to 4K Docking Station
• USB Cable
• CD (Driver and User’s Manual)
• Quick Installation Guide

System Requirements

Operating Systems: Windows® 7 SP1 or later/ Windows® 8/ Windows® 8.1

Connector	Video Output	DP/HDMI Female Connector *
		DVI Female Connector
	Host Upstream Link	USB B Type Female Connector
	HUB Downstream Link	USB A Type Female Connector (USB 3.0 x3, with BC1.2 x1)
	Audio Port	3.5mm stereo mini-jack
	Ethernet Port	RJ45 Connector
	Power	DC power jack
Video	Resolution	DP/HDMI: 3840x2160 *
		DVI: 2048x1152
	Color Depth	16 Bits and 32 Bits
Audio	Channel	2.1 CH
Ethernet	Type	10/100/1000 Base-T
Power	Power Mode	Self-powered
	Power Adapter	Input: AC 100-240V
		Output: DC 5V/4A
Physical Properties	Housing	PC + ABS (Plastic)
	Dimension	189.1(L) x 74.49(W) x 26.32(H) mm
Working Environment	Operation Temperature	10~40 degree
	Storage Temperature	-20~70 degree
Compliance		CE, FCC

* The DP and HDMI connectors can only be used one at a time. Slide the lid in front of the two connectors to uncover the connector you want to use and connect it to the monitor. Please note that when using the DP (or HDMI) and the DVI connector simultaneously, the DP (or HDMI) connector will not be able to reach 4K resolutions.
