HIS RX 480 IceQ X² 4GB
  • RX 480 4GB ICEQ X2_1600p.jpg
  • 5_1600p.jpg
  • 1_1600p.jpg
  • 3_1600p.jpg
  • RX 480 4GB ICEQ X2  彩盒+卡_1600p.jpg
  • RX 480 4GB ICEQ X2  彩盒_1600p.jpg
Product Code HS-480R4LSNR
EAN Code 4895139011586
Cooler IceQ X² Cooler
GPU AMD Radeon RX 480
Core Clock 1266 MHz
Memory Clock 1750 MHz
Memory Size 4096 MB
Memory Type GDDR5
Memory Interface 256 bit
Interface PCI Express x16 (PCI Express 3.0)
Card Dimension 23.5 x 13.0 x 4.0 cm
Box Dimension 34.0 x 24.0 x 8.0 cm
Box Weight 1.09 kg
Availability Immediate

  • New AMD Radeon Graphics
  • Freesync
  • Trueaudio Technology
  • Powertune Technology
  • Zerocore Technology
  • GCN Architecture
  • Crossfire
  • DirectX 12
  • AMD Radeon Graphics
  • AMD HD3D Technology
  • AMD Eyefinity Technology
  • IceQ X²
  • UEFI
  • Display Port
  • DVI
  • Retail Pack

HIS RX 480 IceQ X2 4GB

delivers Premium Gaming Experiences beyond HD

The brand new look of IceQ X2 Cooler comes with Twin-fans and unique metallic fan shroud which is embossed with the silver strong lion icon and engraved with the HIS hexagonal patterns.

Why HIS RX 480 performs better ?

Advanced Composite Heatpipes

  • The Heatpipes are specially made to increase the total surface area for removing heat from GPU



Integrated VRM Heatsink

  • The heatsink is designed to integrate with the main block of Heatsink/Heatpipe
  • Much more effective to transfer heat away from HOT VRM



0dB Fan

  • Prolong the life-span of the fans
  • Start to spin when the GPU temperature reaches about 600C
  • Stop spinning when started & when GPU temperature drops to about 500C
  • Provide a silence environment for enjoying Home Movie & Casual Gaming





What's in the box
  • HIS Graphics Card
  • Driver Disc
  • Quick Installation Guide
  • 8-pin power cable













Model Name
HIS RX 480 IceQ X² 4GB
Chipset AMD Radeon RX 480
Memory Size
4096 MB
Memory Type GDDR5
Core Clock
    Base 1120MHz, Boost Clock 1266 MHz
Memory Clock
7Gbps
Memory Interface
256 bit
Power Supply
Requirement

500W (or greater) power supply with one 75W 8-pin PCI Express power connector recommended.

Max. Resolution
(per Display)

DisplayPort 1.4 - 5120 cx 2880 pixel resolution @ 60Hz

HDMI 2.0b - 4096x2160 pixel resolution @ 60Hz

   Dual -link DVI---2560 x 1600 pixel resolution @ 60 Hz



Interface PCI Express 3.0 x16
Outputs 3 x DP + 1 x HDMI  + 1 x DL-DVI

System Requirements

  • PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard
  • 500W (or greater) power supply with one 75W 8-pin PCI Express power connectors recommended
    NOTE: Minimum recommended system power supply wattage is based on the specific graphics card and the typical power requirements of other system components. Your system may require more or less power. OEM and other pre-assembled PCs may have different power requirements.
  • Minimum 4GB of system memory/ 8GB recommended
    8GB (or more) system memory recommended for AMD CrossFire™ technology
  • Installation software requires CD-ROM drive
  • DVD playback requires DVD drive
  • A display with digital input (HDMI, DisplayPort or DVI) is required
  • Blu-ray™ playback requires Blu-ray drive
  • Supported operating systems include Linux®, Windows® 10 and Windows® 7
  • 64-bit operating system highly recommended.



The terms HDMI and HDMI High-Definition Mutlimedia Interface and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
